| CATALOG No | UGE70C | UEC70CN | UEG100C | UEG100CN | UEG120C | UEG120CN |
| Figure No | QHDX-02-01 | QHDX-02-02 | QHDX-03-01 | QHDX-03-02 | QHDX-04-01 | QHDX-04-02 |
| Mechanical Performance |
|
|
|
|
| Min.Mechanical failing load(KN) | 70 | 70 | 100 | 100 | 120 | 120 |
| Dimensions |
|
|
|
| Nominal diameter D(mm) | 200 | 200 | 200 | 200 | 200 | 200 |
| Nominal spacing P(mm) | 210 | 210 | 210 | 210 | 210 | 210 |
| Nominal creepage distance(mm) | 220 | 220 | 220 | 220 | 220 | 220 |
| Standard coupling | 16C | 16C | 16C | 16C | 16C | 16C |
| Suspending modes | Suspension | Tension | Suspension | Tension | Suspension | Tension |
| Electrical Performance |
Electrode performance of
withstand arc current (min) | Power frequency
current (kA) | 10 | 10 | 10 | 10 | 10 | 10 |
| Time(s) | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 |
Extinguishedarc current at
power frequency refresh
voltage 2500V with gap
distance 15mm(A) | Inductance current | 35 | 35 | 35 | 35 | 35 | 35 |
Capacitance current | 20 | 20 | 20 | 20 | 20 | 20 |
Powerfrequency
discharge voltage with gap
distance 20(kV) | Max | 30 | 30 | 30 | 30 | 30 | 30 |
| Min | 8 | 8 | 8 | 8 | 8 | 8 |
